6159936270
Issue no: 08
Series: G
Item Part number
5 6153942525
6 6153932710
8 6153972585
8 6153969125
8a 6156811260
8b 461993
9 6153969115
10 461953
11 467823
12 471953
13 291923
14 6156160780
15 473803
16 475293
16 443123
16 443113
16 443103
16 443873
16 462143
17 462113
17 443133
17 473333
17 473343
17 475333
17 473593
18 463683
19 443843
20 443623
21 476693
22 476283
22 476273
23 475523
23 475513
24 468093
25 467003
Software and documentation available at:
Qty Description
1 Motor assembly (200 rpm)
1 Case assembly REV
1 Transmission shaft assembly
1 Transmission shaft assembly (200 rpm)
1 Spring
1 Push rod
1 Signal case assembly
1 Adjusting ring
1 Screw M4 x 6
1 Kit Hall effect assembly
2 Washer M3 shake proof
2 Screw M3 x 12
1 Pistol grip assembly
1 Gearbox ratio 6.11 : 1 (2000 rpm)
1 Gearbox ratio 9 : 1 (1500 rpm)
1 Gearbox ratio 12.86 : 1 (1000 rpm)
1 Gearbox ratio 18.33 : 1 (750 rpm)
1 Gearbox ratio 26.19 : 1 (550 rpm)
1 Gearbox ratio 37 : 1 (200 rpm)
1 Clutch module - S4Q (HD)
1 Clutch module - S4Q (STD)
1 Clutch module - S4Q (HD manual)
1 Clutch module - S4Q (STD manual)
1 Spindle push start
1 Spindle lever start / trigger start
1 Case front grip
1 Clutch case (M20 x 1.0 RH)
1 Clutch case (thrust bump)
1 Clutch case
1 Kit 135° angle head □ ¼" drive
1 Kit 135° angle head ¼" Hex drive
1 Kit 90° angle head ¼" Hex drive head
1 Kit 90° angle head □ ¼" drive
1 Warning label
1 Suspension ring
4 / 44
http://resource-center.desouttertools.com
No login/password required.
10/2014
