Care and Cleaning

To clean the xture, disconnect the power by turning off the circuit breaker or by removing the fuse at the fuse box. Use a dry or slightly
□
dampened, clean cloth to wipe the exterior surface of the xture.
□ Do not use any cleaners with chemicals, harsh abrasives, or solvents. Use only a dry soft cloth to dust or wipe carefully.

Troubleshooting

Problem
Tape light strip does not light.
Only part of the LED tape light
strip is lit.
LED tape lights blink on,
then go off.
LEDs farthest from the power
supply are noticeably dimmer.
SPECIFICATIONS
Input Voltage.............................................................12V DC
LED Count............................................................60 LEDs/m
LED Module..........................................................SMD 2835
Chip Size.......................................................................2835
Beam Angle..........................................................120° wide
Tape Height/Width................................................1.3 x 8mm
Possible Cause
The LED is burned out.
The power is off.
The power cord is not plugged in.
The connector has faulty connections. Check you have maintained correct polarity (+ to + and - to -).
The power is wrong.
The circuit breaker is turned off.
The connector has faulty connections. Check connections to the part of the strip that is not lit.
The LED series is damaged.
Your power supply is not adequate
for the length of LED tape light you
are powering.
This is the result of voltage drop.
Solution
Discontinue use of the lamp.
Ensure the power supply is turned on.
Ensure the power cord is plugged into the oulet.
Check all tape light connections and switch or dimmer
connections from the power supply to the LED tape light.
Ensure the power supply is 12V DC.
Ensure the circuit breaker is in the "ON" position.
Con rm that you have maintained correct polarity to the
unlit section.
Cut out and remove the damaged three-LED group and splice
together LED tape strips or replace with a new three--LED
section.
Install a higher wattage power supply or reduce watts used
by shortening the lengths of your LED tape light.
Decrease the length of the 12V power feed wires or use
thicker power feed wires between the 12V power supply
and the tape light.
Use shorter lengths of LED tape light. Refer to
con guration options in these guidelines. Consider a
different con guration.
Contact a quali ed electrician or call the Customer Care
Service Team at 1-877-527-0313, 8 a.m. - 7 p.m., EST,
Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday.
Cuttable..........................................Every 2" approx (50mm)
Lumens.....................................................................2858 lm
Color Accuracy (CRI)........................................................~80
Listings..........................................................ETL, RoHS, FCC
Country of Origin...........................................................China
