HealthSmart DigiScan Manual De Uso página 7

How To Take Measurement
1. To measure temperature in the EAR:
Take off the FOREHEAD COVER from the thermometer, carefully place the
measuring probe along the ear canal into the ear, and then press the
Measure key to start the measurement. You'll hear 1 beep and continue to
hold. After the completion of measurement you'll hear two short beeps.
Now you can read the result on the display or hear it through a speaker,
if the TALK function is on. You can measure again after "000" disappears.
2. To measure temperature on the FOREHEAD:
Put the FOREHEAD COVER on the thermometer, place it gently in the middle
of the forehead, between eyebrows and hair line. Press the Measure key to
start the measurement. You'll hear 1 beep and continue to hold. After the
completion of measurement you'll hear two short beeps. Now you can read
the result on the display or hear it through a speaker, if the TALK function
is on.
3. W hen body temperature is over 99.6°F (37.6°C), the measure key will light in
a red color indicating a fever.
4. The result will be stored into memory automatically. If 30 sets of memory are
stored already, the first set of data will be removed, and the current
measurement will be stored as the last record.
5. M easure 3 times maximum in a consecutive way. It is possible that a proper
body temperature measure is obstructed despite of a normal recovery. For
continuous measurement up to 4 times or above, at least wait for 10 minutes
before new measurement.
6. D isplaying the result of measurement:
A. D isplaying the true value of the result for measurements between
89.6°F – 109. 3°F (32.0°C and 42.9 °C);
B. "HI" displayed if the results are higher than 109.3°F/42.9°C;
C. "LO" displayed if the results are lower than 89.6°F/32.0°C.
7
