Door reversal

DV7700J-03170Q-05_EN-US.indd 33
If you want to reverse the direction of the
door, we recommend you call a qualified
service technician.
1. Unplug the power cord.
2. Remove the four hinge screws from the
door.
3. Remove the door by lifting it.
4. Remove the two screws from the holder-
lever, and then remove the cover-holder.
5. Assemble the holder-lever on the
opposite side using the screws that were
removed from the holder-lever-in Step
4.
6. Assemble the cover-holder on the
opposite side.
7. Remove the two cover-hinges.
8. Assemble the two cover-hinges on the
opposite side.
NOTE
Use a flat head screwdriver(-) to remove the
cover-holder's cover-hinge.
