Applications:
With / without drill stand Core bit diameter
Hand-held / dry With dust extraction,
Hand-held / wet Without water collection system, 12– 62 mm dia.
Hand-held / wet With water collection system,
Drill stand / wet Without water collection system, 12–152 mm dia.
Drill stand / wet With water collection system
When drilling in an upwards direction, a wet-type vacuum cleaner must be connected to the water collection system.
G Horizontal drilling with vacuum attachment is per-
missible only when an additional means of securing the
drill stand is employed. The drill stand may be used for
overhead drilling only when fastened by an anchor or
by means of a quick-release brace.
G Drilling into materials containing asbestos is not per-
missible.
G Changes or modifications to the tool are not permis-
sible.
G To avoid the risk of injury, use only original Hilti acces-
sories and additional equipment.
G Observe the information printed in the operating
instructions concerning operation, care and mainte-
nance.
G The tool is intended for professional use.
G The tool may be operated, serviced and repaired only
by authorised, trained personnel. This personnel must
be informed of any special hazards that may be encoun-
tered.

3. Tools and accessories

Designation
Vacuum pump
Quick-release brace
Water collector system for hand-held use
Water collector system for drill stand use
Drill stand
Wheel assembly
DD-CS M12S-SM clamping spindle
DD-CN SML clamping nut

4. Technical data

Nominal voltage: *
Nominal power:
Nominal current: *
Frequency
Printed: 08.07.2013 | Doc-Nr: PUB / 5069520 / 000 / 01
12–162 mm dia.
12– 62 mm dia.
12–132 mm dia.
G The tool and its accessories may, nevertheless, pre-
sent hazards when used incorrectly by untrained per-
sonnel or when used not as directed.
G The machine may be operated only when connect-
ed to an adequately-rated electric supply equipped
with an earth (ground) conductor.
Items supplied:
– Power tool
– Side handle
– Hilti toolbox or cardboard box
– Operating instructions
– Cleaning cloth
– Wrench SW 19
– Grease
– Protective glasses
110 V 120 V 220 V
1700 W 1800 W 1900 W
16 A 15 A 9.1 A
50/60 Hz 50/60 Hz 50/60Hz
Drilling direction
All directions
Not upwards
All directions
Not upwards
All directions
Item no.
47034
9870
370462
370460
370461
232228
251830
251834
230 V 240 V
1900 W 1900 W
8.7 A 8.3 A
50/60Hz 50/60Hz
