ASSEMBLY - TOWER WITHOUT FRONT SHROUD - STANDARD
5
STEP 4
4 NAME
Flat washer
M10
NAME
G
Plate support
G
9
G
TOOLS
Fixed Wrench 17 mm
Qty 8 NAME
4x
Hex head screw
M10X65
4
50%
4
8
4
8
16
Qty 9 NAME
4x
Hex nut insert
M10
Qty
4x
