2.2 System Requirements

Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable modem that has an RJ45 connector (you do not need it
if you connect the router to Ethernet)
Each PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connectors
TCP/IP protocol must be installed on each PC
Web browser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator
6.0 or later

2.3 Installation Environment Requirements

Not in direct sunlight or near a heater or heating vent
Not cluttered or crowded. There should be at least 2 inches (5 cm) of clear space on all sides
of the router
Well ventilated (especially if it is in a closet)
Operating temperature: 0 ~40
Operating Humidity: 5%~90%RH, Non-condensing

2. 4 Connecting the Router

Note: Prior to connecting the router, be sure to power off your computer, DSL/Cable modem, and
the router. To achieve maximum wireless coverage, tilt the router's antennas outward at 45° angle.
1. Connect one end of a network cable to the WAN port of the router and connect the other end of
the cable to the DSL/Cable modem.
2. With another network cable, connect one end of the cable to your computer's network card and
connect the other end to one of the LAN ports of the router.
3. Power on the DSL/Cable modem and wait for the lights on the modem to settle down.
4. Power on the router by connecting one end of the supplied power adapter to the power jack of the
router and connecting the other end to an electrical outlet.
5. Power on your computer.
6. Make sure the WAN, WLAN, and the LAN ports that the computer is connected to are lit. If not, try
the above steps again.
