MECHANICAL AND ACOUSTICAL FEATURES

DIMENSIONS

LVX XM12 incorporates a 12" woofer (2.5" voice coil) and a 1"
compression driver (1.4" voice coil) in coaxial configuration
accommodated in a wooden cabinet protected by a PVC coating
and weighing 20.1 kg. The overall dimensions of a single
speaker are as follows: 515 x 460 x 370 mm. The monitor can be
easily carried and handled by a single person thanks to its side
handles. Standard 35-mm dia. pole mount allows for use in an
installation for PA sound reinforcement, as well as dual monitor
configuration.

SOUND COVERAGE

The monitor's particular geometry shown in the diagram
ensures 90 x 70° coverage. This ensures good dispersion
performance in all use configurations, including vertical
arrangement. Coaxial configuration provides excellent off-
axis coverage and excellent sound results at close listening
distance.
