6.1 Numeric indicator (display)


1

2

6.2 Led

2
3
4
5

6.3 Keys

6
7
8
Main display normally displays the actual kiln temperature.
During confi guration or programming it will display setpoint
value, number of segments or other values (temperature, rate,
dwell etc.).
Only ATR901:
Secondary display shows the number of segment in progress
or the number of segment which is being programmed.
Only ATR900:
Leds shows the segment number of the fi ring cycle. All leds
are fl ashing when a delayed start has been programmed.
When the cycle foresees more than 7 segments, the 7th led
stays ON also for the additional segments.
Led is ON when the operator is entering a temperature or if
the function "simple controller" is running.
Led is ON when the operator is entering a time value for each
segment of a program.
Led fl ashes when the control output is on during a fi ring cycle
or when the function "simple controller" is running.
Increases the displayed value:
• Parameter value during confi guration
• Setpoint value if operating as "simple controller" (see 8.3)
• Time or temperature value if entering a fi ring cycle.
• Scroll through the parameters during confi guration.
• Scroll through the segments within the selected program
Decreases the displayed value:
• Setpoint value if operating as "simple controller" (see 8.3)
• Time or temperature value if entering a fi ring cycle
• Parameter value during confi guration
