Power Linking - Chauvet DJ Intimidator Spot DUO 155 Guía De Referencia Rápida

Intimidator Spot Duo 155 QRG
What Is
Included
To Begin
Description
Overview
AC Power

Power Linking

· Intimidator Spot Duo 155
· Hanging Bracket with
Mounting Hardware
Unpack your Intimidator Spot Duo 155 and make sure you have received all parts
in good condition. If the box or contents appear damaged, notify the carrier
immediately, not Chauvet.
The Intimidator Spot Duo 155 has two Intimidator Spot 155 moving heads pre-
mounted on a single bar. Control options include automated programs, Sound-
Active modes, and DMX. Pan and tilt functions are available for each moving
head. Lighting options include separate color and gobo wheels, as well as multiple
built-in Master/Slave programs.
Front Panel View
Microphone
Back Panel View
Safety
Loop In/Out
Tripod Adjustment
Knob
This product has an auto-ranging power supply that can work with an input
voltage range of 100 to 240 VAC, 50/60 Hz.
To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
For the maximum number of Intimidator Spot Duo 155 that can be
power linked at 120 V or at 240 V, see the User Manual or the label on the
product.
· Power Cord
· Warranty Card
· Quick Reference Guide
Menu
Buttons
Moving
Yokes
Focusing
Lenses
DMX
3
Digital Display
Power In
Power Out
Cooling Fan
EN
Fuse
Holder
