3.5 Schematic diagram and wiring diagram

Heater or
Contactor box
A1 Valk
A2 Ruskea
A3 Vihreä
NOTE! See the sauna heater instruction
for correct installation location

Sauna room

Sauna heater
Heater or
Contactor box
Sensor cable
4
3
2
1
1 Blue
2 White
3 Red
4 Yellow
Vit White Weiss
Brun Brown Braun
Grön Green Frün
Sensor
2
Silicone 4 x 0.25mm
Image. 1 Principle of the installation
Connector strip
4
3
2
1
Control panel Easy
B1 Kelt Gul Yellow
B2 Harm Grå Grey
B3 Rosa Ljusröd Pink
B4 Sin Blå Blue
B5 Pun Röd Red
Control panel
1601-16 (Easy)
IP X4
Helo
HIG H
SAUNA 6h
2
LiYY 8 x 0.25mm
helo
DSA
DSA Door switch
SET
Power supply
230V – 240V 1N / 2~
230V 3~
400V – 415V 3N~
7
Limiter
Gelb
Grau
Rose
Blau
Rot
