Simrad Marine TV
Display
No receptable satellite in
scanning
interchang- the entire search range
ing with
complete
Cannot find a satellite
Cannot find a stored satel-
lite
Search for stored satellite
takes longer, even though
there are no obstructions
in the view to the satellite

C Replacement parts

● Electronic box
● LNB
● Sensor and limit switch unit
● Control unit

D Optional parts

● LNB mounting with variable skew
All parts are available from you local authorized dealer/installer.
Unauthorized attempts made to open the radome will void any warranty
claims.
Problem Remedy
- Check, if the program selected
on the receiver is transmitted by
the wanted satellite
- Check, if any superstructures
are obstructing the sight to the
satellite
- Check, by using footprint cards
(e.g. www.satcodx.com), that the
boat is inside the coverage area
(footprint)
Check, if superstructures obstruct
the view to the satellite, and
restart the search mode
- Check, if superstructures
obstruct the view to the satellite
- Delete the stored satellite and
restart the search mode
If the location of the vessel changes,
the angles of the satellite may have
moved. Modify angles of the satel-
lite at the new location with the
function
Upd Sat
English-35
, see section 4.2.
