22 INSTALLATION
5
Insert a strain relief
junction box. Tighten the ring nut
it in place.
6
Insert the electrical cable through the hole in
the strain relief. Tighten 2 screws to secure the
cable.
7
Pull the existing wires through the openings
in the junction box. Tighten 2 screws
reassemble the junction box in the appliance.
through the hole in the
b
to secure
c
to
d
8
Pair the white, black, and green wires to the
matching colored wires from the dishwasher.
Then twist on the provided wire nuts
to connect the corresponding wires.
9
Wrap electrical tape
connection.
10
Fold the connected wires back into the
junction box and screw on the junction box
cover.
WARNING
• Verify that the black wire is hot (120 V). If
not, or if you are unsure of the power supply,
have it checked by a licensed electrician.
CAUTION
• Do not leave stripped wire exposed. Trim
stripped wire to fit completely inside wire
nuts.
tightly
e
around each
f
