20 | English
Large Surface (see figure G)
A metal, large surface (e. g. a metal plate) is within the sensor
range. The object depth is 2 cm. The measuring tool emits an
audio signal.
Troubleshooting – Causes and Corrective Measures
Error
Measuring tool cannot be switched on.
Measuring tool switched on but does not
react
Display indication: "S l i p p i n g W h e e l" Wheel losing contact with
Display indication: "S p e e d i n g"
"Temperature over range"
"Temperature under
range"
"Strong radio signal
detected"

Maintenance and Service

Maintenance and Cleaning

 Check the measuring tool each time before use. In case
of visible damage or loose components inside the measur-
ing tool, safe function can no longer be ensured.
Keep the measuring tool clean and dry at all times to ensure
proper and safe working.
Do not immerse the measuring tool in water or other fluids.
Wipe away debris or contamination with a dry, soft cloth. Do
not use cleaning agents or solvents.
1 609 92A 27E | (8.3.16)
Many Unclear Signals (see figures H–I)
When many objects are shown in the standard start display,
the wall probably consists of many hollow spaces. To broadly
block out the hollow spaces, switch to the "Metal "operating
mode. When there are still too many objects being shown,
carry out several height-offset measurements and mark the
detected objects on the wall. Offset marks are an indication
for hollow spaces, whereas marks on a line indicate an object.
Cause Corrective Measure
Batteries empty Replace batteries
Batteries incorrectly Check if the batteries are inserted correctly
inserted (wrong polarity)
Take out batteries and reinsert again
Measuring tool too warm or Wait until operating temperature range is reached
too cold
Press the start button 11 and take care that the
the surface two bottom wheels have contact with the wall
while moving the measuring tool; in case of uneven
walls, position a thin piece of cardboard between
the wheels and the wall
Measuring tool has been Press the start button 11 and move measuring tool
moved to quickly slowly over the wall
Wait until operating temperature range is reached
Wait until operating temperature range is reached
Measuring tool switches off automatically. If possi-
ble, eliminate the interfering radio waves, e.g.
WLAN, UMTS, radar, transmitter masts or micro-
waves, then switch the measuring tool on again.
Pay attention that the maintenance flap 7 is al-
ways properly closed. The maintenance flap
may only be opened by an authorised after-
sales service centre for Bosch power tools.
If the measuring tool should fail despite the care taken in man-
ufacturing and testing procedures, repair should be carried
out by an authorised after-sales service centre for Bosch pow-
er tools. Do not open the measuring tool yourself.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the measuring tool.
Store and transport the measuring tool only in the supplied
protective pouch.
