Setting up your dishwasher

CONNECTION OF DRAIN HOSES

Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making
sure to avoid bending or crimping it. The top of the hose must be at a height between 40 and 100 cm. The
free end of the hose must not be immersed in water to avoid the back flow of it.
NOTE
The top of the hose must
be at a height between
40 and 100 cm.
The free end of the hose
must not be immersed in
water.

POSITION THE APPLIANCE

Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that
can be positioned either to the right or the left sides to facilitate proper installation.

Levelling the Appliance

Once the appliance is positioned for levelling, the height of the
dishwasher may be altered via adjustment of the screwing level of the
feet. In any case, the appliance should not be inclined more than 2°.

START OF DISHWASHER

The following should be checked before starting the dishwasher.
1. the dishwasher is level and fi xed
2. the inlet valve is opened
3. There is no leakage at the connections of the conducts
4. the wires are tightly connected
5. the power is switched on
6. the inlet and drain hoses are not knotted
7. All packaging materials and printings have been taken out of the dishwasher
ATTENTION: After installation please put this manual in a safe place. The contents of this manual can
be useful to users.
38_ Setting up your dishwasher
DW5500M-02437D-0 EN.indd 38 DW5500M-02437D-0 _EN.indd 38 1
Drain pipe
Counter
40 mm
