Step 11
Halogen Bulb by screwing bulb into socket. Install Light Kit
Blank Cover by aligning slots on light kit/fan cover to dimples
sembly Housing. Turn glass or cover clockwise to lock securely
an motor housing while turning light kit/cover to ensure proper installation.
Dimples
Light Assembly Housing
Halogen Bulb
Slots
Light Kit Assembly or
Blank Cover

Electrical Connections

ack fan wires to black outlet wire. Connect white fan wire to
wire and green grounding lead wire from the grounding
o the supply circuit
A). Use wire
provided with your
White
se strands or loose
should be present. Black
upward and carefully
ing into outlet box.
witches are employed,
ould be UL listed for use
fan.
UTION: Always turn off power at breaker before
mpting any wire connections.
All manuals and user guides at all-guides.com
Ground
Black
Green
White
Setting Frequency Switches
The remote control unit is operated by a set of frequency switches and are
preset at the factory. The switches are located in the back of the remote
control unit and in the lower part of the fan on the receiving module. The
switches can be set in any position as long as both the remote control unit
and receiving module switches are set the same. All (RF) modules &
Transmitters come from the factory with the dip switches set in the (ON)
position.
To replace battery, simply push down on tab and slide housing cover off.
Snap 9-Volt battery onto wire terminal and replace into remote housing.
Slide housing cover back onto remote control unit.
1 2 3 4
ON
Remote
Control Unit
1 2 3 4
ON
Battery
Terminal
PUSH
Housing
Cover
Remote
Housing
