ion
ant: When using an existing outlet box, be sure the box is securely attached
building structure and can support the full weight of the fan. Failure to do
result in serious injury or death.
Step 1
circuit breakers and wall switch to the fan
ne leads.
: Failure to disconnect power supply prior to installation
lt in serious injury or death.To reduce the risk of shock,
must be installed with an isolating wall control/switch.
Step 2
make sure blades are at
om any obstruction.
wnrod length to
des are at least
e floor.
Step 3
ring mounting bracket, screw "J" hook (S9) into ceiling outlet
ndary support means. Secure mounting plate (1) using screws
(S2) directly to the outlet box. If not mounting to an outlet box,
ews (S1) and mount securely to a beam or joist.
Ceiling
OUTLET BOX
t mount directly
r ceiling tile.
k installation is a
irement only.
Screws & Washers
for Mounting Plate (S2)
All manuals and user guides at all-guides.com
30"
0.75m
Min.
84"
(2.1m)
Min.
Support Beam
"J" Hook (S9)
Mounting Plate (1)
Wood Screws
& Washers (S1)
4
Hang the fan motor/mounting bracket (2) onto the hook that is positioned
on the mounting plate (1).
1. Hang the fan motor (2) onto the hook that is positioned on the mounting
plate (1). Connect fan wires to ceiling wires: white fan wire to white outlet
wire, black to black and green to green. Wire connectors (S5) are provided
for your convenience. If an additional blue wire is present then also connect
the blue wire to the black wire. (Optional light kit may be wired to individual
wall switches, if desired.)
2. After connections are made, turn splices upward and push carefully into
outlet box. Separate blue and black wires on one side of the box, and white
and green wires on the other side.
There are 3 colored wires coming from the top of the motor (including
ground wire).
NOTE: Wire connectors that are not pushed up into the outlet box may in time sag and
rub against the top of the motor housing. This sound can be mistaken for bearing noise.
Mounting Plate (1)
Ground (Green)
Black
Blue
Fan Motor (2)
Wire Connnections
Outlet Box Fan wires
Black Black
(Hot wire for fan)
Green Green
(Ground wire)
White White
(Neutral wire)
Black Blue
(Light kit wire)
Step 4
"J" Hook (S9)
Wire Connectors (S5)
White
