Control panel overview

5
3 4
10
9
1. Indicator for depth adjustment
2. Manual depth indicator
3. Joystick for forward and rearward movement of the
left drive wheel
4. Joystick for forward and rearward movement of the
right drive wheel
5. Steering lock
6. Lock for depth adjustment wheel
7. Lift lever
8. Depth adjustment wheel
4
1
2
14
11 12 13
6
15
9. Tracking control
10. Speed adjustment
11. ON/OFF buttons for drive motor
12. Emergency stop button
13. Ammeter
14. ON/OFF buttons for drum motor
15. Switch for direction of rotation, drum motor
16. Operator presence control (OPC)
7
8
1816 - 002 - 22.03.2023
16
