TECshow NAVIGATOR 24 XL Manual De Usuario página 4

7 UP/chase reverse
8 LCD Display
9 Delete/Rev one
10 Aux 1
11 Insert % or 255
12 Aux 2
13 Edit/All rev
14 Record/shift
15 Audio/
Page A B
16 Blind
17 Chase Rev
18 DARK
19 HOME
20 PARK
21 Mode/
Rec. speed
22 Tap sync
23 Hold
24 PAGE
25 FULL ON
P. 4
NAVIGATOR 24XL
ENGLISH VERSION
Up function to modify a scene in Edit Mode, Chase Reverse is used to reverse the
chasing direction of a program under Speed Slider control.
Show the current activity or progamming state.
Delete a step in a scene or reverse the chasing direction of any program.
Patchable; used to control a channel in 1 of 2 modes of operation.
Insert is to add 1 step or steps into a scene. % or 255 is used to change the display
value cycle between % and 0-255.
Patchable; used to control a channel in 1 of 2 modes of operation.
Edit is used to activate Edit Mode; All Rev is to reverse the chasing direction of all
programs.
Record is used to activate Record Mode or program a step; Shift functions the
alternate function of other buttons only.
Audio activate audio sync of chase; Page A-B switches the channel faders between
1-24 mode and 25-48 mode. Press and hold record and Page A-B to switch be-
tween the 2 channel pages.
Takes the channel out of a program temporarily in Chase. Scene Mode.
Reverses the direction of a chase playback.
Used to temporarily blackout overall output.
Used to deactivate the Blind on a given channel
Used to select Single/Mix Chase, bring Channel 13-24(37-48= to full of current
setting, or momentarily program a ascene into Master B slider depending on the
current mode.
Used to activate the operating mode; Rec Speed sets the speed of any programs
chasing in Mix Mode.
Repeatedly tapping this button will establish the chase Speed.
Used to momentarily maintain current scene.
Tap to select pages of scenes from 1-4(Page A) and 1.4(Page B).
Momentarily bring all channels (1-48) to full intensity.
