EN
WS-200SP | WS-200FT Pressure Spray Guns
8.1 INSPECTION AND REPLACEMENT STANDARD
WHERE TO INSPECT
Each hole passage of air cap set (1) and fluid nozzle set (2-1).
Packings and O'rings.
Leakage from seat section between fluid nozzle (2-1) and fluid
needle set (2-2).

9. SPARE PARTS LIST

CODE DESCRIPTION
Ref.
AIR CAP SET
93001300 WS-200SP-01
1
93002070 WS-200FT-01
93002190 WS-200FT-02
FLUID NOZZLE SET + FLUID NEEDLE SET
93007240 WS-200SP-08
93007490 WS-200SP-10
93007550 WS-200SP-12
93007620 WS-200SP-14
93007650 WS-200SP-16
2-1
93007660 WS-200SP-18
+
2-2
93002180 WS-200FT-08
93002150 WS-200FT-10
93002130 WS-200FT-12
93003420 WS-200FT-14
93003480 WS-200FT-16
93003500 WS-200FT-18
93007750 BAFFLE RING SET
4
03810620 NEEDLE PACKING SET
6
93001561 PATTERN ADJUSTMENT SET
7
93001640 *AIR VALVE SEAT SET
8
93001680 O RING
8-1
93001690 AIR VALVE
9
93001700 AIR VALVE SPRING
10
93001710 FLUID ADJ. GUIDE SET
11
93002820 NEEDLE SPRING SET
12
93593530 NEEDLE SPRING
12-1
93001760 NEEDLE SPRING PACKING
12-2
93001780 FLUID ADJUSTMENT KNOB
13
93001790 AIR VALVE SHAFT
14
93001801 AIR ADJUSTMENT SET
15
93001820 TRIGGER SET
16
93001870 TRIGGER STUD
17
93001960 **HEX. SOCKET BUTTON BOLT
18
93505910 SPANNER
19
W2COM6163 BRUSHES (5 pcs.)
20
W2COM6162
21 TWISTED BRUSHES ø10mm (5 pcs.)
8
REPLACEMENT PART
Replace air cap or fluid nozzle if they are crushed or deformed.
Replace if deformed or worn out.
Replace them if leakage does not stop after fully cleaning fluid noz-
zle (2-1) and fluid needle set (2-2).
If you replace fluid nozzle (2-1) or fluid needle set (2-2) only, fully
match them and confirm that there is no leakage.
4
2-1
1
n
18
21
20
19
NEVER REMOVE FLUID NIPPLE GUN BODY! Any malfunc-
tions resulting by the removal of this part will not be
covered by the Warranty. In case of replacement contact
your Technical Service directly.
Marked parts are wearable parts.
n
n
NOTE
n
When ordering parts, specify gun model, part name with No. and
marked No. of air cap set, fluid nozzle and fluid needle.
To disassemble Air valve seat ref. 8, use 10 mm Allen wrench (Non ball
*
point type). (not enclosed)
n
**To disassemble Hexagon socket button bolt ref. 18, use 2.5 mm Allen
n
wrench. (not enclosed)
FLUID NOZZLE SET
SIZE ø mm (inch)
0.8 (0.031)
n
1.0 (0.039)
1.2 (0.047)
n
1.4 (0.055)
1.6 (0.063)
1.8 (0.071)
0.8 (0.031)
1.0 (0.039)
1.2 (0.047)
1.4 (0.055)
1.6 (0.063)
1.8 (0.071)
6
5
9
17
16
15
FLUID NEEDLE SET
MARK
WS200 /08SP
WS200 /10SP
WS200 /12SP
WS200 /14SP
WS200 /16SP
WS200 /18SP
WS200 /08FT
WS200 /10FT
WS200 /12FT
WS200 /14FT
WS200 /16FT
WS200 /18FT
7
8
14
8-1
10 11
2-2
12
13
12-1 12-2
MARK
WS20012
WS20016
WS20012H
WS20016H
