26 | English

Intended Use

The machine is intended for cutting, roughing,
and brushing metal and stone materials without
using water.
For cutting stone, a special cutting guide with
dust extraction protection guard (accessory)
must be used.
With approved sanding tools, the machine can
be used for sanding with sanding discs.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Spindle lock button
2 On/Off switch
3 Auxiliary handle
4 Grinder spindle
5 Protection guard with locking screw

Technical Data

Angle Grinder

Article number
Rated power input
Output power
Rated speed
Grinding disc diameter, max.
Thread of grinder spindle
Thread length (max.) of grinder spindle
Reduced starting current
Weight according to EPTA-Procedure
01/2003
Protection class
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltage and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may
vary.
Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of un-
favourable mains system conditions. Malfunctions are not to be expected for system impedances below 0.25 ohm.
1 609 929 L91 | (23.7.08)
6 Locking screw for protection guard
7 Mounting flange with O-ring
8 Grinding/cutting disc*
9 Clamping nut
10 Quick-clamping nut
11 Protection guard for für grinding cup*
12 Grinding cup*
13 Two-pin spanner for clamping nut*
14 Hand guard*
15 Spacer discs*
16 Rubber sanding plate*
17 Sanding sheet*
18 Round nut*
19 Cup brush*
20 Cutting guide with dust extraction protec-
tion guard *
21 Diamond cutting disc*
*The accessories illustrated or described are not in-
cluded as standard delivery.
GWS ... 22-180 22-230
Professional H
3 601 ... H81 Y.. H82 X..
W 2200
W 1450
-1
min 8500
mm 180
M 14
mm 25
–
kg 5.0
/ II
*
22-230 22-230
H H JH
H82 Y.. H82 Z..
2200 2200 2200
1450 1450 1450
6500 6500 6500
230 230 230
M 14 M 14 M 14
25 25 25
– –
5.2 5.2 5.2
/ II / II / II
