Smalvic FI-74MT Manual De Instrucciones página 24

• the time display shows the programming icon
time missing to the start of cooking;
• the icon signals that programming is activated;
When the automatic program starts, an acoustic signal will warn
that cooking is starting.
The oven switches on (the cooking mode
and time programming behaves in the same way as the cooking
duration function, with the difference that oven start-up has
been postponed.
In fact, the cooking duration icon
cooking end icon and the display will show the desired
cooking duration.
When the time has expired, an intermittent acoustic signal will
inform the user, the oven switches off and the display will be
active and flashing.
The acoustic signal deactivates using any key or automatically
after 3 minutes.
Automatic cooking recipes
There are 32 automatic cooking recipes in the oven with
sequence times and temperatures already set, realised on the
basis of cooking tests performed by specialised cooks. The
program allows modifications to be made to automatic recipes
in order for you to customise them. Factory settings can be
restored at any time.
The system also allows the creation of another 20 recipes at
your discretion, which are completely customised according to
your cooking methods.
Follow the instructions given below to use programming.
ATTENTION
The food probe cannot be applied during use of the
programmed recipes or those created by the user.
Automatic recipes
Enter the recipes menu.
• Switch the oven on using key 1.
• Press key 2 until the flashing "MAN" symbol appears on
the display.
• Press the "+" key, flashing P AUTO appears.
• Press key 6 or wait 5 seconds for automatic confirmation.
• The central part of the display shows the first programmed
recipe P01 alternately to the time set, the total duration of
the recipe is shown in the top left of the display and the pre-
heating temperature in the top right.
Select the desired programmed recipe.
• Follow the 4 points in paragraph "A".
• Press key 2.
• P will start to flash.
• Press key 6 to confirm. The P and P01, which represent the
first recipe programmed, start to flash.
• Press the "+" key until the pre-selected recipe is reached
(P01; P32).
• Press key 6 to confirm.
• Start the programmed cooking by pressing the START key
(key 3).
If you wish to postpone the programmed cooking, follow the
instructions in the paragraph below.
22
and the
icon is activated)
will appear instead of the
Setting the postponed start-up of a programmed recipe
• Follow the instructions in paragraph "B" up to point n°. 8.
• Press key 2 until the flashing "COOKING END TIME"
icon is reached. The display shows the cooking end time in
the top left.
• Press key 6 to confirm, the cooking end time starts to flash.
• Press the " + " key to postpone the cooking end time.
• Press key 6 to confirm or wait 5 seconds for automatic
confirmation.
• Press the START key.
The oven is in Pause mode, the time remaining until activation
of the programmed cooking appears in the top left of the display.
In the event of a temporary and unexpected power cut, the
process is annulled automatically.
Modifying a recipe with respect to standard factory settings
• Follow the 4 points in paragraph "A".
• Press key 2.
• Press key 6, P and P01 start to flash.
• Press the + key to reach the pre-selected recipe (the oven has
32 programmed recipes (P01/P32).
• Press key 6 to confirm the recipe or wait 5 seconds for
automatic confirmation.
• Press the ENTER key (key 6) for at least 3 seconds. Flashing
"Func PRE" appears.
• Press the "+" key to select the function to use for oven
pre-heating.
• Press key 6 to confirm, the temperature index flashes.
• Press the "+" / "-" key to set the pre-heating temperature.
• Press key 6 to confirm. Pre-heating duration flashes on the
display.
• Press the "+" / "-" key to modify pre-heating duration.
• Press key 6 to confirm. The "Func F1" code appears, which
identifies the cooking sequence immediately following
pre-heating:
• Follow the instructions from point 9 to point 14 to confirm the
cooking characteristics (temperature and duration function).
The oven requests to set/modify a maximum of 5 consecutive
cooking sequences named F1-F2-F3-F4-F5.
NOTE: : If one or more cooking sequences are to be excluded,
when set function is requested, go to "00" using the "+"
and "-" keys. At the end of the settings, the display shows
"DEF NO".
• Press key 6 to confirm the changes.
Restore recipe according to factory parameters
• If the recipe is to be taken to factory conditions, follow the
instructions from point 7 to point 17. At the "DEF NO" request,
press the "+" key
• Flashing "SURE DEF YES" will appear.
• Press key 6 to confirm the restoring of the factory values of
the individual recipe.
Customised recipes
The oven allows the creation and memorisation of n° 20 user
recipes (from U01 to U20)
To annul the recipe, follow the instructions in paragraph E)
