PLAMENICI
Nominalna snaga za pojedinačni plamenik kW
Naziv plina Plamenik
PLIN G20 20mbar GL8B/M GL8+8B/M
PRIRODNI PLIN (METAN) 6GL18B/M
GL10B/M GL10+10B/M
II2H3B/P
GL7+7M
GL15M GL15+15M 9GL15M 9GL15+15M
SUPPLY PRESSURE: (min÷max)
GL18... SGL18... 9GL18... S9GL18... LX9GL18...
G20 17÷25 mbar GL20M GL20+20M
9GL22... S9GL22... LX9GL22...
9GL22.../R S9GL22.../R LX9GL22.../R
GL30B/M
PLIN G30/G31 30mbar GL8B/M GL8+8B/M
GPL
6GL18B/M
GL10B/M GL10+10B/M
II2H3B/P
GL7+7M
GL15M GL15+15M 9GL15M 9GL15+15M
SUPPLY PRESSURE: (min÷max)
GL18... SGL18... 9GL18... S9GL18... LX9GL18...
G30 25÷35 mbar
GL20M GL20+20M
9GL22... S9GL22... LX9GL22...
G31 25÷35 mbar
9GL22.../R S9GL22.../R LX9GL22.../R
GL30B/M
MOD.
Qn
V
GL8B/M 6GL18B/M GL10B/M GL7+7M
GL8+8B/M GL10+10B/M
3,3 3,48 3,45
N°:
kW: Hz: 50/60
GL15M GL18... GL20M
GL15+15M SGL18... GL20+20M
9GL15M 9GL18...
9GL15+15M S9GL18...
LX9GL18...
4,60 4,23 7,0 5,50
Ø Glavne Ø Tlak na izlazu
mlaznice inter-ignition iz ventila
135 - -
140 - -
140 - -
155 - -
157 - -
200 70 -
175 - -
195 - -
235 - 10 mbar
160 - -
90 - -
95 - -
93 - -
105 - -
100 - -
130 45 -
115 - -
120 - -
120 - -
107 - -
HR
IPX2
9GL22... GL30B/M
S9GL22...
LX9GL22...
9GL22.../R
S9GL22.../R
LX9GL22.../R
6,67 4,38
Podešavanje Ø Glavne
primarnog zraka mlaznic
Zatvoreno 51
1,0 mm 51
Zatvoreno 51
11,0 mm 51
9,0 mm 51
6,0 mm Podesivo
20,0 mm 51
16,0 mm 51
Otvoren 51
Zatvoreno 51
1,5 mm 35
Otvoren 35
5,0 mm 35
11,0 mm 35
9,0 mm 35
6,0 mm 25
Otvoren 35
Otvoren 30
Otvoren 30
3,0 mm 35
