Connect the dust extraction adapter (12) to the
machine, then connect the dust bag (13) to the
adapter. Empty the dust bag regularly so that the
vacuuming performance remains intact.
A vacuum cleaner can be directly connected to
the dust extraction adapter when use of a vacuum
cleaner is preferred.
5. Operation
Never use the spindle lock while the
machine is running.
Switching on and off
Fig. A
• To switch the machine on slide the on/off
switch (1) forwards.
• To switch the machine off, depress the on/off
switch (1), the switch will automatically move
to the 'off' position.
Never use the spindle lock to stop the
motor.
Marking the workpiece
Fig. E
Before starting with the Biscuit Jointer the
workpieces must be marked as following.
• Place the two surfaces which must be
connected, with their connecting side to each
other
• Clamp the work pieces and mark the center of
the groove by drawing a perpendicular line
• Several joints will be required for larger
workpieces. The distance between two drawn
lines should be at least 10cm.
Sawing grooves
Fig. F
• Set and check the cutting depth on the
machine
• Set the angle on the machine
• Set the height on the machine, take care for
setting the height, the groove for the biscuit
dowel must be in the middle of the workpiece.
• Make sure the workpiece is securely clamped
• Position the machine on the workpiece, the
marked centerline (15) must be in line with the
line drawn on the workpiece
• Hold the machine with both hands and switch
the machine on.
8
• Push the motor base carefully forward as far
as possible.
• Move the motor base backward and switch
the machine off.
For workpieces thinner than 16 mm it is
not possible to cut the groove in the
middle of the workpiece without adding
an adjustment plate below your
workpiece (fig. G).
Joining the workpieces
When the grooves in both workpieces have been
made the workpieces can be joined together.
• Put glue in both grooves.
• Place the biscuit dowel in the groove of one
workpiece.
• Place the other workpiece on the biscuit
dowel.
• Fasten the workpieces and wait till the glue is
dry.
User tip for connecting two workpieces
• Saw a groove as big as one biscuit into the
first workpiece
• Place the biscuit with good glue (according
the material) into the groove
• Saw a longer groove into the other workpiece
• Now both workpieces can be positioned easily
towards each other (clearance to correct)
• Fasten the workpieces and wait till the glue is
dry
Move the machine in the same direction
as the direction of rotation. See arrow
on top of the machine.
Fine adjusting the cutting depth
Fig. B
When the cutting depth is not correct, it can be
adjusted as following.
• Move the motor base (3) as far as possible
backwards.
• Loosen the nut on the fine adjustment screw
while keeping the screw in position by using a
screw driver
• Increase the cutting depth by turning the
screw (10) counterclockwise.
• Decrease the cutting depth by turning the
screw (10) clockwise
• Repeat the procedure till the cutting depth is
correct.
