Assembly Plan
1/4'' Washer
11"
1 - 3/4''
Panhead
Screw
Fig. 29a
Safety Handle
Fig. 29
1. Mount safety handle in the Rock Wall opening approximately
2. Reference (Fig. 29a) for Safety Handle placement.
Deck Surface
Safety Handles.
11'' above the deck surface (Fig. 29).
