Specifications

3.1 General Specifications

Operating
environment
Operating
temperature
and humidity range
Storage
temperature
and humidity range
Dustproofness and
waterproofness
Standards
Power supply
Continuous
operating time
Dimensions
Maximum diameter
of measurable
conductor
Mass
Product warranty
period
Accessories
Options
Indoors, pollution degree 2, altitude up to 2000 m (6562 ft.)
-10°C to 50°C (14°F to 122°F), 80% RH or less
(non-condensing)
-20°C to 60°C (-4.0°F to 140°F), 80% RH or less
(non-condensation)
IP40 (EN 60529)
With clamp sensor closed.
Safety EN 61010
EN 61557 (EN 61557-13, Class2, 30 A/m)
EMC EN 61326
LR6 Alkaline battery ×2
Rated supply voltage: 1.5 V DC ×2
Maximum rated power: 450 mVA
When using two LR6 Alkaline batteries (reference value at 23°C)
• Approx. 40 hours
(25 Ω measurement, backlight off, Z3210 not installed)
• Approx. 35 hours
(25 Ω measurement, backlight off, Z3210 installed and wire-
less communication)
Approx. 73W × 218H × 43D mm (2.87"W × 8.58"H × 1.69"D)
(excluding projections)
φ32 mm
Approx. 620 g (21.9 oz) (excluding batteries)
3 years
Reference: p.2
Reference: p.3
HIOKI FT6380B983-00
3.1 General Specifications
Chapter 3
