1.

SPECIFICATIONS

POWER SUPPLY:-
AMBIENT OPERATING
TEMPERATURE
MONITOR:-
COIN ACCEPTOR:-
DIMENSIONS:-
WEIGHT
ACCESSORIES:-
Assembled
Monitor Cabinet
Seat Assembly
Header Assembly
Assembled
Monitor Cabinet
Seat Assembly
Header Assembly
Page 28
230v /350watts AC
+5°C to +25°C
Hantarex 28" Polo-Medium Planar
(Type 02193240)
Mars CashFlow - 4 Channel Dispense
1600(w) x 870(d) x 1990(h)
1600(w) x 870(d) x 1590(h)
452(w) x 820(d) x 1220(h)
1470(w) x 370(d) x 450(h)
379kg
302kg
26kg each
25kg
Keys: (Cash Door) ............ 2
(Coin Door) ............. 2
(Back Door) ............. 2
IEC Mains Lead ...................... 1
Operators Manual ................... 1
Monitor Manual ....................... 1
CashFlow Documents ............ 1
DVD Rom ............................... 2
Security Card (Dongle) .......... 2
M5 Security Wrench ............... 1
Potentiometer 1kW 40° ........ 1
Potentiometer 1kW 270° ........ 1
M6x20 Pozi head screw ......... 3
1"x¼" Flat Washer .................. 3
M6 Spring Washer .................. 3
M10x25 Hex Head Screw ....... 8
M10 Spring Washer ................ 8
M10 Flat Washer .................... 8
