DRAIN BODY INSTALLATION
11
11A
11 POP-UP INSTALLATION
Install and adjust Pop-Up (11A) using separate instructions supplied with the Pop-Up
assembly.
12
12 UNIT START UP
Turn on hot and cold water supplies, and check for leaks above and below the sink.
FAUCET FUNCTIONS
13
HOT
OPEN
13 FAUCET FUNCTION
COLD valve: close-counterclockwise, open-clockwise; HOT valve: close-clockwise,
open-counterclockwise.
ENGLISH
COLD
OPEN
5
MAINTENANCE & CARE
14
14 VALVE CARTRIDGE REPLACEMENT
Turn off water supplies and relieve pressure before working on your faucet (see
step 2). Remove Handles (14A) and Place Plastic Seal Rings (14B) (see step 7). Unscrew
Retainer Nut (14C) by turning it counter-clockwise and lift out Cartridge Assembly (14D)
and inspect. Replace parts as necessary. Reassemble parts by reversing steps.
CAUTION: Maintenance
DISASSEMBLY
1. Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price
Pfister Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp
cloth to clean and shine. Use of polish, detergents, abrasive
cleaners, organic solvents or acid may cause damage. Use of
other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar
substance are not acceptable for public areas or Commercial
use. Installation of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfister.com
• Installation Support
• Care and Warranty Information
14A
14B
14C
14D
