24

ATTACHING THE LEGS

The turntable comes with its own legs so it can stand alone. Alternatively,
the legs can be removed and it can sit on an existing table or shelf. To
attach the legs to the turntable, screw each individual leg to the metal
plate on the rear of the unit. See diagram below for more details
Note: If placing the turntable on a surface, attach the included rubber
feet.

INITIAL SET-UP

Power supply
• Ensure that the mains voltage (100-240V, 50/60Hz) of your home
• corresponds to the operating voltage of the adapter.
• Connect the power adapter to the wall outlet.
• Connect the DC connector to the "DC IN" (5V 1A) jack on the rear of the
unit.
Amplifier Connection (if required)
You can listen to your new turntable using the built-in speakers or you
may wish to connect it to your existing Hi-Fi system. Connect the "line
out" RCA ports to the "line input" on your mixer or amplifier using an RCA
cable (not supplied)
• Red plug into the right channel input
• White plug into left channel input
