9 ADJUTMENTS

ARMREST ADJUSTMENT

The inclination of the armrests can be modified by
turning the adjustment knob.
When turning the knob to the outside (+) the front part
of the armrest will be lifted, when turning the knob to
inside (-) it will be lowered.

BACKREST ADJUSTMENT

Moving the locking lever upwards loosens the
notching of the backrest adjustment.
After the adjustment, the locking lever must latch into
the desired position. It should not be possible to move
the backrest into another position when it is locked.
For an ergonomic use the backrest can be adjusted
in a range of –5 to +30 degrees (15 steps of 2.5
degrees each).
MAINTENANCE
Dirt can impair the function of the seat,
so make sure you keep your seat clean!
Upholstery does not need to be removed from
the seat frame for cleaning.
Caution: Take care with the backrest - it may jerk
forward and cause injury!
When cleaning the backrest cushion the backrest
must be held in place when operating the
backrest lever.
Attention: Do not clean the seat with a
pressure washer!
During cleaning the upholstery should not be
soaked through.
Use a standard commercially available
upholstery or plastic cleaning agent. Test first
for compatibility on a small, concealed
area.
JACOBSEN FAIRWAY 305 Series CG2
SAFETY AND OPERATION & MAINTENANCE MANUAL
en-45
