Return temperature. (Only available in installations with AZX6SONDPROTEC protection
probe). This allows you to define the system's cut-off temperatures for the protection of
the AC unit in heating mode (32°C, 34°C and 36°C) and cooling mode (6°C, 8°C and 10°C).
By default, the system's heating cut-off temperature is set to 34°C and the cooling cut-off
temperature is set to 8°C.
•
Q-Adapt. (Only for Airzone Think thermostats.)
1.
In direct expansion units. This allows you to define the airflow control algorithm that
best fits the duct installation. The options available are:
- Maximum: The system operates at maximum speed regardless of the number of zones.
- Power: The system operates at a higher speed than in Standard mode to ensure airflow
is increased.
- Standard (by default): The system changes speed depending on the number of zones.
- Silence: The system operates at a lower speed than in Standard mode to improve noise
reduction.
- Minimum: The system operates at minimum speed regardless of the number of zones.
2.
In fancoil units 0-10V. This allows you to set the minimum (1.5V by default) and
maximum (10V by default) working voltage of the fan of the controlled AC unit, in 1V
steps. The minimum voltage will correspond to the desired minimum speed of the AC
unit and the maximum voltage will correspond to the maximum speed. The average
speed will correspond to the midpoint between the two.
•
Radio channel. This allows you to enable/disable the system's wireless association channel.
•
Information. (Only for Airzone Think thermostats). This allows you to display information
about:
- Zone: firmware, zone, association, actuator or communications status.
- System: firmware, IAQ firmware, settings and information on system and installation
controllers.
- Devices: indicates the elements connected to the system.
- Webserver: firmware, IP address, gateway, MAC and PIN.
•
Reset system. (Only available for Airzone Blueface master thermostats). This allows you to
reset the system by returning it to factory settings. To reconfigure the thermostats, go to the
Initial configuration section.
•
Centralized control. This allows you to define whether or not your installation has a
centralized controller. By default, it will be configured as deactivated.
•
BACnet. (Only in installations with AZX6BACNET). This parameter shows the device ID,
uplink port, IP address, subnet mask and gateway IP and allows you to modify them. Click
on the desired value, modify the parameters and click on the option to confirm. The default
values are:
- Device ID: 1000
- Port: 47808
- IP address: DHCP
•
Protection mode. (Only available in Airzone Blueface thermostats and if the system
detects an H2 error in the indoor unit). This allows you to disable the delay in the closing of
the motorized elements.
