1. MAIN HANDLE
2. AuxILIARy HANDLE
3. uPPER LOCKING KNOB
4. LOwER LOCKING KNOB
5. AuxILIARy HANDLE LOCKING LEvER
6. SAFETy GuARD
7. SPACER GuARD
8. EDGER wHEEL
9. LINE CuTTER
10. TELESCOPIC SHAFT
11. CuTTING HEAD COvER (See Fig M)
12. CAP RELEASE LATCH (See Fig M)
13. SPOOL (See Fig M)
14. CuTTING HEAD (See Fig M)
15. EyELET (See Fig M)
16. LINE FEED BuTTON (See Fig L)
6 6
17. BATTERy PACK
18. BATTERy PACK RELEASE LATCH
19. CHARGER
20. CHARGED INDICATOR LIGHT (Green)
21. CHARGING INDICATOR LIGHT (Red)
22. wALL MOuNT BRACKET (See N.1) (wG150.1, wG150.2 and wG150.3)
