SBC800 Battery Charger
SBC800 Charger
The SBC800 cradle charger holds eight
SB900 batteries and is designed to fit into
a rackmount drawer. It may be used in any
appropriate location with adequate space
and ventilation.
Features
• Charge up to eight SB900 batteries
• Cable routing for better wire
management
• LED icons for battery status

Included Components

• SBC800 Charger
• PS60 Power Supply
SB900 batteries not included.
14
Power
1. Connect DC power cable to input jack on
bottom of charger. Finger tighten lock nut
for a secure connection.
2. Route the cable along the desired chan-
nel and press into place to secure.
3. Connect power cable to AC Adapter.
WARNING:
• Do not use pliers or any other tools to
tighten lock nut. DC power cable must be
attached before charger unit is installed.
• Do not plug in power supply unit until DC
connection and charger are in place.
• After securing the charger, plug the power
cable into a properly grounded outlet.
The SBC800 has no power switch. When
plugged in, the charger is ready. The LEDs
illuminate after batteries are inserted.
