5-1 Removing the Monitor from the Monitor Base

The monitor is heavy (approx. 100kg). At least 4 people are required
1. Remove 6off Security screws (M5x30), and remove the front cover panel.
2. Disconnect the connectors.
3. Remove 2off Hex head screws (M10x130), spring and special washer from
the front underside of the monitor.
4. Remove 2off Pozi head screws (M5x30) and remove the cover bracket.
to lift the monitor from the monitor base.
Page 37
