Operating Instructions

Important Safety Instructions

INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
This manual contains safety, operational
and maintenance information. Contact
your Campbell Hausfeld representative
if you have any questions.
When using tools,
basic precautions
should always be followed, including
the following:
CALIFORNIA PROPOSITION 65
This product can
expose you to
chemicals including lead, which are
known to the State of California to
cause cancer and birth defects or
other reproductive harm. For more
information go to www.P65Warnings.
ca.gov.
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.

Tool Components and Specifications

• REQUIRES: 0.3 CFM with
10 fasteners per minute @ 90 PSI
• AIR INLET: 1/4 inch NPT
• FASTENER SIZE RANGE:
3/8 inch to 1-1/4 inch
• MAGAZINE CAPACITY:
100 fasteners per load, 18 gauge
• STAPLES: 1/4 inch crown
• WEIGHT: 2 lbs., 15 oz.
• LENGTH: 10-1/2 inch
• HEIGHT: 9-1/2 inch
• MAXIMUM PRESSURE: 100 PSI
• PRESSURE RANGE: 60 PSI to 100 PSI
www.campbellhausfeld.com
ILLINOIS LEAD POISONING
PREVENTION ACT
IF EATEN OR CHEWED. COMPLIES WITH
FEDERAL STANDARDS.
GENERAL
a. To reduce the risks of
electric shock, fire, and
injury to persons, read all
the instructions before
using the tool.
b. Be thoroughly familiar with the
controls and the proper use of the
equipment. Follow all instructions.
Contact your Campbell Hausfeld
representative if you have any
questions.
c. Only persons well acquainted with
these rules of safe operation should
be allowed to use the unit.
labels and manual. Failure to follow
warnings, dangers, and cautions could
result in DEATH or SERIOUS INJURY.
WORK AREA
a. Keep the work area clean and well
lighted. Cluttered benches and dark
areas increase the risks of electric
shock, fire, and injury to persons.
Quick
Clear
Nose
Work Contact Element (WCE)
b. Do not operate the tool
CONTAINS LEAD.
MAY BE HARMFUL
c. Keep bystanders, children, and
PERSONAL SAFETY
a. Stay alert. Watch what you are
b. Dress properly. Do not wear loose
Read and
understand tool
c. Avoid unintentional starting.
Cap Exhaust
Trigger
Fastener
Discharge Area
2
in explosive atmospheres,
such as in the presence of
flammable liquids, gases,
or dust. The tool is able to create
sparks resulting in the ignition of
the dust or fumes.
visitors away while operating the
tool. Distractions are able to result in
the loss of control of the tool.
doing and use common sense
when operating the tool. Do not
use the tool while tired or under
the influence of drugs, alcohol,
or medication. A moment of
inattention while operating the
tool increases the risk of injury to
persons.
clothing or jewelry. Contain long
hair. Keep hair, clothing, and
gloves away from moving parts.
Loose clothes, jewelry, or long
hair increases the risk of injury to
persons as a result of being caught
in moving parts.
Be sure the switch is off before
connecting to the air supply. Do not
carry the tool with your finger on
Latch Button
Magazine
