Craftsman Engine Model 265-jU For Snow Thrower Model 247.88780
Ref. Part No.
1 710-04968 Bolt
2 951-11054 Valve Cover
3 731-07059 Breather Hose
4 726-04101 Hose Clamp
7 751-11124 Pivot Locking Nut
8 751-11123 Valve Adjusting Nut
10 710-04902 Pivot Bolt
15 710-04933 Bolt
18 951-10292 Spark Plug
19 751-12010 Muffler Assembly
20 710-05276 Stud
21 951-11285 Muffler Gasket
22 712-04214 Nut
23 710-05002 Bolt
24 951-10962 Heater Box Base
26 710-04915 Bolt
28 710-05101 Stud, M6 x110
29 710-04919 Bolt
33 951-12011 Carburetor Assembly
37 712-04213 Nut
44 951-10961 Heater Box
45 710-05275 Bolt
47 951-10648 Push Rod Kit (incl. intake and exhaust rod)
49 715-04090 Dowel Pin
57 951-11113 Air Shield
59 951-11356 Governor Arm Shaft
60 736-04461 Washer
62 714-04074 Cotter Pin
64 951-11369 Radial Ball Bearing
65 951-10307 Flywheel Key
68 715-04092 Dowel Pin, 7 x 14
69 715-04096 Dowel Pin, 9 x 14
70 951-11371 Crankcase Cover Gasket
72 710-04932 Cover Bolt
75 951-11368 Oil Seal
78 736-04440 Washer
80 951-11370 Oil Seal
81 751-12013 Ignition Coil
83 751-12012 Fuel Line Kit (incl. clamps and fuel line)
85 951-10370 Oil Drain Assembly, includes 78, 79
PARTS LIST
Description
29
Ref. Part No.
86 951-10805 Flywheel
87 951-10909 Cooling Fan
88 951-10911 Starter Cup
89 712-04209 Nut
90 951-10647 Valve Kit (incl. intake and exhaust valve)
92 751-12014 Blower Housing
93 736-04455 Washer
94 710-04974 Bolt
95 751-12015 Recoil Starter
96 731-05696 Starter Handle
98 951-11104 Governor Spring Bracket
99 751-12016 Governor Shield
100 751-12017 Governor Spring
101 951-10664 Throttle Return Spring
102 951-10665 Governor Rod
104 712-04212 Nut
105 710-04908 Bolt
113 751-11913 Dipstick Tube
115 751-11912 Dipstick
119 951-11106 Governor Arm Bracket
121 951-11903 O-Ring
122 751-11934 O-Ring
125 710-05182 Bolt
126 715-04088 Dowel Pin
127 951-10645A Electric Starter
128 710-04979 Bolt
129 951-11109 Blower Housing Shield
130 951-10639A Primer
131 710-04945 Bolt
132 710-04938 Drain Bolt
— 952Z265-JU Engine, Complete
56 951-11283 Oil Fill Plug Assembly
73 951-11577 O-Ring
Oil FIll Plug
74 —
— 951-11063 Valve Cover Kit (Not Shown)
2 951-11054 Valve Cover
5 951-11565 Head Cover Gasket
— 751-11913 Oil Fill Tube Assembly
751-11913 Dipstick Tube
113
951-11903 O-Ring
121
Description Qty.
—
1
1
—
1
1
—
1
2
