Maytag MMMF6030 Guia De Inicio Rapido

MICROWAVE OVEN HOOD COMBINATION QUICK START GUIDE MMMF6030
OPERATING INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS, located in your appliance's Owner's Manual, before operating this appliance.
Setting Clock When First Plug In
Step 1.
The first time you power up, the clock time
will be blinking 12 00 on the display.
Step 2.
Open the door.
Step 3.
Use number keypad to set hours and
minutes, the range is between 1:00-12:59, without
AM/PM. It is a 12 hour clock.
Step 4. Press Settings keypad or wait for 5 seconds
to confirm.
Using Hood Light
Press Light button setting the hood light among
HIGH->LOW->OFF
Using Hood Fan
Press Fan/Vent Fan button setting the vent fan among
HIGH->MEDIUM->LOW->OFF
NOTE: For more detailed instructions on specific functions, see the online Control Guide.
ALUMINIUM FOIL AND METAL
Always use oven mitts or pot holders when removing dishes from the microwave oven.
Aluminum foil and some metal can be used in the microwave oven. If not used properly, arcing (a blue flash of
light) can occur and cause damage to the microwave oven.
OK for Use
� Browning dish (Follow manufacturer recommendations.)
� Ceramic glass, glass
� China, earthenware (Follow manufacturer recommendations.)
� Melamine (Follow manufacturer recommendations.)
� Paper towels, paper plates, napkins (Use non-recycled paper.)
� Plastic wraps, bags, covers, dinnerware, containers (Follow manufacturer recommendations.)
� Pottery and clay (Follow manufacturer recommendations.)
� Silicone bakeware (Follow manufacturer recommendations.)
� Wax paper.
Do Not Use
Metal cookware and bakeware, gold, silver, pewter, non-approved meat thermometers, skewers, twist ties, foil
liners such as sandwich wrappers, staples, and objects with gold or silver trim or a metallic glaze should not be
used in the microwave oven.
OVEN VENT(S)
The microwave oven vent is flushed to the cabinet. It will be opened
automatically when the microwave is operating, and it should not be
blocked or covered since it allows the inlet of fresh air into the cooling
system. Also the bottom vent should not be blocked or covered since
it allows the inlet of fresh air into the cooling system and the outlet of
hot air from the cooling system. Blocking or covering vents will cause
poor air circulation, affecting cooking, cleaning, and cooling results.
W11595049A
Using Your Microwave Oven to
Cook
Step 1. Open the door.
Step 2.
Place food inside the microwave oven.
Step 3.
Select food classes.
Step 4.
Enter/Sense the amounts.
Step 5.
Close the door.
Step 6.
Press Start to start the cooking.
Step 7.
The Cancel/Stop button can be use to cancel
the function during or after cook time.
A
B
Combination Microwave Oven
A. Microwave oven vent
B. Bottom vent
CLEAN GREASE FILTER:
The Grease Filter is on the underside of microwave oven. Clean
monthly.
To clean the Grease Filter:
1. Disconnect power.
2. Remove the Grease Filter by loosing the screw, sliding it out
of the bottom plate.
3. Remove the Charcoal Filter out of the Grease Filter.
4. Clean the Grease Filter with mild cleanser and scouring pad,
or clean it with dishwasher.
5. After cleaning, dry it up, reattach the Charcoal Filter, put the
Grease Filter back to the bottom plate. Securely tighten the
screw.
REPLACING GREASE FILTER:
If the Grease Filter has been damaged, replace a new one.
To replace the Grease Filter:
1. Disconnect power.
2. To remove the Grease Filter by loosing the screw, sliding it out of the bottom plate.
3. Remove the Charcoal Filter out of the Grease Filter.
4. Replace a new Grease Filter. Reattach the Charcoal Filter.
5. Put the Grease Filter back to the bottom plate. Securely tighten the screw.
REPLACING CHARCOAL FILTER:
The Charcoal Filter is behind the Grease Filter. It cannot be cleaned and should be replaced every 6 months,
while the display scroll the filter alert "Change the Charcoal Filter, Reset reminder in Settings."
To replace the Charcoal Filter:
1. Disconnect power.
2. Remove the Grease Filter by loosing the screw, sliding it out of the bottom plate.
3. Remove the Charcoal Filter out of the Grease Filter.
4. Replace the old Charcoal Filter with a new Charcoal Filter.
5. Put the Charcoal Filter back to the Grease Filter.
6. Put them back to the bottom plate. Securely tighten the screw.
To remove the filter alert and reset filters duration:
After the Charcoal Filter is replaced, to remove the filter alert on the display, retrieve another 6 months duration.
1. Press Settings button repeatedly until Filter Reset.
2. The display scrolling "Press 1 to reset filter reminder."
3. Press 1 keypad to confirm. "Filter Reset" on the display.
The Charcoal Filter retrieve another 6 months duration now.
NOTE: Order the Charcoal or Grease Filter, see the "Online ordering information" section.
ONLINE ORDERING INFORMATION
For detailed installation instruction and maintenance information, please see the Owner's Manual included with
your appliance.
For information on any of the following items, a full cycle guide, warranty, detailed product dimensions, or for
complete instructions for use and installation, please visit https://www.maytag.com/owners. This may save you
the cost of a service call.
However, if you need to contact us, use the information listed below.
United States:
1-800-344-1274
Maytag Brand Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
IMPORTANT: Retain this guide for future use.
A
B
C
D
Combination Microwave Oven
A. Bottom Plate C. Screw
B. Charcoal Filter D. Grease Filter
