Cables, connectors, and mini-dock symbols

The cable kit includes cables for both the MDSm and the MDS Lite II. You need to use only the cables
for your product.
Table 2: Connectivity Symbols on Mini-Dock
Symbol Definition
DC input
Print control
USB
Ethernet
RS-232 (DVD recorder or bar code scanner)
S-video out
S-video in
DVI video out
Composite video out
Audio out
ECG/Footswitch
14 Cables, connectors, and mini-dock symbols
