ELECTRODES ADJUSTMENT

Two ignition electrodes and a control electrode have been fitted. They should be positioned according to the indications
supplied in the figure below.
IMPORTANT: the ignition electrodes and the control electrode must never touch the diffuser, the draught tube
or other metallic parts. If this were to happen they would no longer work, thus impairing operation of the burner
itself.
The position of the electrodes should always be checked after any work on the combustion head.
EM 16-E
Control electrode
EM 26-E
Control electrode
