1. PARTS AND COMPONENTS

1. Upper basket
2. Spray arms
3. Lower basket
4. Descaler
5. Filters
6. Detergent dispenser
7. Rinse aid dispenser
8. Cutlery tray
Control panel. (Fig. 2)
1. Power icon: press this icon to switch on or off the appliance.
2. Delay icon: press this icon to delay the start time of any cycle automatically up to 24
hours.
3. Programme selection icon: press this icon to scroll through the different washing
programmes. The indicator light of the corresponding programme will light up to show
the selected washing programme.
4. ALT additional function icon: press this icon to select the additional 3 in 1 function. The
upper or lower parts of the appliance are washed. The corresponding indicator light
flashes.
5. Start/Pause icon: press this icon to start or pause a washing programme.
6. Child lock icon: press both icons for 3 seconds (indicated in the control panel). The device
will be locked and no touch icon could be used.
7. Programme indicator light: when you select a washing programme, the corresponding
indicator light lights up.
8. Rinse aid refill indicator light: the indicator lights up when it is necessary to refill the rinse
aid dispenser.
9. Salt refill indicator light: the indicator lights up when it is necessary to refill the water
softener with salt.
10. Child lock indicator light: the child lock is activated when you press the child lock icons for
3 seconds. The child lock indicator light stays on after flashing 6 times.
11. 3 in 1 function indicator light: the indicator lights up when the additional function is
selected.
12. Upper part washing indicator light: it lights up when the upper spray arm is washing.
13. Upper part washing indicator light: it lights up when the upper spray arm is washing.
14. Digital display: it shows the remaining time.
NOTE:
the graphics in this manual are schematic representations and may not exactly match the
device.
