method: absolute
ready!
start
create method
delete method
system paramete
ViscoPump parameter
Id: Sample XYZ
lot: 12075ADC
usr: Jonny Miller
temp equ. Time
meas. 1 out of 10
meas. 2
245.56 s
result corr.
average
stand. dev.
correction
corr. ave.
Abs Visc
122 s
120 s
= 234.56 s
= 0.001
= 0.34 s
= 233.22
= 3.322 mm ^2 / s
Fig. 4. Main menu, selection
Display of the set method (e.g. absolute)
Start the set method
Create/change the set method
Delete the method
Change/set the system parameters
Change&/set the ViscoPump parameters Fig. 23
Fig. 5 Input after start
Id: The designation of a method; in the present
case the field is empty (after a reset, or yet
unused) or contains the last input
lot: The lot designation (as above)
usr.: User (as above)
No mandatory entry, press "Enter" to proceed
Fig. 6
If "pre. temp." (fig. 17) was set, this screen will
display the remaining time of the running
temperature pre-adaptation in terms of seconds.
Fig. 7 Measurement after temperature pre-
adaptation
After temperature pre-adaptation, the set number
of measurements (Fig. 17) will be preformed and
displayed here on a running basis in steps of 1 s.
Fig. 8 Measurement value at the end of a
measurement
Upon completion of a measurement, the
respective result will remain on the display until
the next measurement begins.
Fig. 9 Display of the measurement result
Example: Absolute measurement with
correction
The present example shows the result of an
absolute measurement in which the Hagenbach-
Couette correction was applied. The average
shown corresponds to the (exemplary!) amount,
reduced by the number of correction seconds
which are also shown.
