ORIGINAL OPERATING INSTRUCTIONS
TE 7-A cordless rotary hammer
It is essential that the operating instructions
en
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents

1 General information

2 Description
3 Insert tools, accessories
4 Technical data
5 Safety instructions
6 Before use
7 Operation
8 Care and maintenance
9 Troubleshooting
10 Disposal
11 Manufacturer's warranty - tools
12 EC declaration of conformity (original)
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
16
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation "the
power tool" always refers to the TE 7-A cordless rotary
hammer.
Operating controls and parts 1
Chuck
@
Function selector switch
;
Control switch
Page
=
Forward / reverse switch
16
%
Side handle with depth gauge
17
&
Interface for TE DRS-M dust removal module
19
(
Battery
19
)
Release buttons
20
+
23
24
26
27
28
29
29
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning: Warning:
electricity caustic
substances
