_Origo_E100_E200_E300.book Seite 10 Freitag, 13. November 2009 5:10 17
Mounting the stove
6
Mounting the stove
You can fit the stove into the countertop of your kitchen.
6.1
Selecting the installation location
When selecting the installation location, observe the following instructions:
Select a well-ventilated location for the device.
Allow a minimum of 20 cm² (3 sq in) per burner, e. g. for E200:
2 x 20 cm² = 40 cm²
(2 x 3 sq in = 6 sq in).
Select a covered location where the stove is preserved from direct splash-
ing by water or other liquids.
Ensure the minimum distances according to fig. 2, page 2.
Avoid cabinet storage space above the stove.
Otherwise you risk burns and fire when reaching over the stove.
Do not operate the device in spaces where danger of explosion is present.
6.2
Installing the stove
Caution – Danger of damaging the device!
a
Before drilling any holes, make sure that no electrical cables or oth-
er parts of the vehicle can be damaged by drilling, sawing and filing.
➤ Cut a rectangular hole into the countertop (dimensions see following
table):
Model
E100
E200
E300
➤ Place the stove in the middle of the cutout.
➤ Secure the stove using a non-hardening compound which should be laid
between the glass-ceramic and the countertop.
This permits later removal of the appliance without damage if service
necessary.
10
Dimensions (L x W x D)
282 x 302 x 80 mm
516 x 282 x 80 mm
508 x 467 x 80 mm
Dometic ORIGO
1
7
5
11
/
x 11
/
x 3
/
in
8
8
32
5
1
5
20
/
x 11
/
x 3
/
16
8
32
3
5
20 x 18
/
x 3
/
in
8
32
in
