VIVID DISPLAY INDICATORS
Your Pro X7™ Vivid Display™ incorporates the following illuminated indicators:
PinSeeker™ Indicator (1)
Aiming Reticle (2)

Battery Life Indicator (3)

Active Laser (4)
Distance Displayed in Yards/Meters (5)
BATTERY LIFE INDICATOR
Battery Indicator:
Full charge
2/3 battery life remaining
1/3 battery Life remaining
Battery Indicator Blinks - Battery needs to be replaced and unit will not be operable.

INSERTING THE BATTERY

Remove the Posi-Thread™ battery door by lifting the battery door tab and then rotating counter clockwise. Insert a
3-volt lithium battery into the compartment negative end first, then replace battery cap.
(CR123)
Note: It is recommended that the battery be replaced at least once every 6 months.
ACTIVE LASER
Crosshairs surrounding the aiming circle indicate that the laser is being transmitted. Once a range has been acquired,
you can release the power button. The crosshairs surrounding the circle will disappear once the power button has been
released (i.e. the laser is no longer being transmitted).
PinSeeker Slope & E.S.P
4
3
PinSeeker beyond E.S.P range— 20196, 205107, 205108
103
PinSeeker & E.S.P "Play-As"
2
1
5
7
