IB514001EN
Installation Instructions - Crosstour MAXX
Instructions d'installation - Crosstour MAXX
Instrucciones de instalación - Crosstour MAXX
WARNING
Make certain power is OFF before starting installation
or attempting any maintenance. Risk of fire/electric
shock. If not qualified, consult an electrician.
WARNING
Make certain power is OFF before starting installation
or attempting any maintenance.
WARNING
Risk of Electric Shock—Disconnect power at fuse or
circuit breaker before installing or servicing.
WARNING
Risk of Burn—Disconnect power and allow fixture to
cool before servicing.
WARNING
Risk of Personal Injury— DO NOT mount luminaire
within 6" of a combustible surface. DO NOT handle
luminaire by the lens.
IMPORTANTe: Read before installing fixture. Retain for future reference.
SAFETYe: This fixture must be wired in accordance with the National Electrical Code and applicable local codes and
ordinances. Proper grounding is required to insure personal safety. Carefully observe grounding procedure under
installation section.
TOOLS REQUIREDe: Phillips head screwdriver, electrical wiring tools, drill, 9/32" drill bit, tape measure.
MATERIAL NOT INCLUDEDe: Wall anchors, washers, mounting bolts, silicone sealant, liquid tight conduit, and wire nuts.
APPLICATIONe: Crosstour MAXX LED luminaires are designed for outdoor, wet location use not to exceed 40°C ambient
(50°C ambient for HA models). Approved for wall/surface applications in down light or uplight (invert) mount. For
thru-branch wiring utilize 4-12 AWG, 90°C wire.
WARNING
Risk of Personal Injury— Fixture may become
damaged and/or unstable if not installed properly.
Tighten all fixture components to their
recommended torque values. Do not lift pole into
place by securing lifting device to lighting fixture or
mounting arm.
These instructions do not claim to cover all
N
otee:
details or variations in the equipment, procedure,
or process described, nor to provide directions
for meeting every possible contingency during
installation, operation or maintenance. When
additional information is desired to satisfy a
problem not covered sufficiently for user's purpose,
please contact your nearest representative.
Specifications and dimensions subject to change
without notice.
Brand Logo
reversed out of
black
INS #
INS #
