You can check the location of your
nearest authorised repair agent by
contacting your local Black & Decker
office at the address indicated in this
manual. Alternatively, a list of authorised
Black & Decker repair agents and full
details of our after-sales service and
contacts are available on the Internet at:
www.2helpU.com
Battery (fig. G)
Z
When disposing of the product,
the battery must be removed
as described below and
disposed of in accordance with
local regulations.
If you want to dispose of the product
yourself, the battery must be removed as
described below and disposed of in
accordance with local regulations.
Warning! Disconnect the appliance from
the power supply before removing the
battery.
Discharge the battery by operating
u
the appliance until the motor stops.
Take the accessories from the
u
appliance.
Remove the screws (9).
u
Open the appliance.
u
Remove the battery and the attached
u
motor and switch module (10).
Use a screwdriver to detach the
u
battery from the motor and switch
module.
Place the battery in suitable
u
packaging to ensure that the
terminals cannot be short-circuited.
Take the battery to your service
u
agent or a local recycling station.
Warning! Once removed, the battery
cannot be refitted.
Technical data
NV19XXYZ H2 NV24XXYZ H2
Voltage V 2.4
Battery type NiCd/NiMH NiCd/NiMH
Weight kg 0.65
Voltage
Battery type
Weight
Voltage
Battery type
Weight
Charger
Model
Input voltage V
Output voltage V
Amperage
Approx.
charging time
Weight
Model
Input voltage V
Output voltage V
Amperage
Approx.
charging time
Weight
Model
Input voltage V
Output voltage V
Amperage
Approx.
charging time
Weight
Level of sound pressure according to EN 60704-1:
Sound pressure (L
European Community patent application
number: 000 540 745 & 000 540 752
European Community design application
number: 000 541 230 & 000 540 752
2.4
DUSTBUSTER is a registered trademark
of the Black & Decker Corporation.
0.65
ENGLISH
NV36XXYZ H2 NV48XXYZ H2
V 3.6 4.8
NiCd/NiMH NiCd/NiMH
kg 0.7 0.85
NV60XXYZ H2 NV72XXYZ H2
V 6.0 7.2
NiCd/NiMH NiCd/NiMH
kg 0.9 0.95
*A035015D *A050020D
NV19/NV24 NV36
230 230
AC
3.5 5
AC
mA 150 200
h 24 24
kg 0.2 0.2
*A070015D *A075020D
NV48 NV60
230 230
AC
7 7.5
AC
mA 150 200
h 24 24
kg 0.2 0.2
*A090020D
NV72
230
AC
9
AC
mA 200
h 24
kg 0.2
) < 70 dB(A), uncertainty (K) 3 dB(A)
pA
