Long shafts bend easily and degrade
true run.
We recommend PROXXON collet
chucks for optimal true running.
Using the machine
Important!
Always wear protective goggles when
using the machine.
Never use damaged grinding wheels or
bent shafts.
1. Switch on machine at switch 4
(Fig. 1) and set the appropriate ope-
rating speed at button 1
(Fig. 1).
Optimum grinding results are achieved
through uniform speed and not by app-
lying excessive pressure.
Small cutters/bits = high speed,
Large cutters/bits = low speed.
2. When cutting or engraving, hold the
machine as if it were a pen (Fig. 3),
being careful not to occlude the vent
slits.
3. For roughing down, grip the machine
as if it were a hammer (Fig. 4).
Care and maintenance
When finished using the machine, unp-
lug it and remove any dust cling ing to
vent slits.
Disposal:
Please do not dispose of the device in
domestic waste! The device contains
valuable substances that can be recyc-
Note:
led. If you have any questions about
this, please contact your local waste
management enterprise or other corre-
sponding municipal facilities.
EC-Declaration of conformity
Name and address of the manufacturer:
PROXXON S.A.
6-10, Härebierg
L-6868 Wecker
Product designation:
Article No.:
In sole responsibility, we declare that
this product conforms to the following
directives and normative documents:
EU EMC Directive 2004/108/EC
DIN EN 55014-1 / 02.2010
DIN EN 55014-2 / 06.2009
DIN EN 61000-3-2 / 03.2010
DIN EN 61000-3-3 / 06 2009
EU Machinery Directive 2006/42/EC
DIN EN 60745-1 / 01.2010
Date: 07.05.2012
Dipl.-Ing. Jörg Wagner
PROXXON S.A.
Machine Safety Department
The CE document authorized agent is
identical with the signatory.
FBS 12/EF
28462
