OPERATION AND SERVICE INFORMATION
Read all of Manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings

CONTROLS AND INDICATORS

Vehicle controls and indicators consist of:
•

key/light switch

•

direction selector

•

choke

•

fuel gauge

•

low oil pressure indicator light

•
accelerator pedal
•
combination service and park brake pedal
•
horn
KEY/LIGHT SWITCH
Located on the dash panel, this switch enables the basic
electrical system of the vehicle to be turned on and off by
turning the key. To prevent inadvertent operation of the
vehicle when left unattended, the key should be turned to
the 'OFF' position and removed (Ref Fig. 2 on page 2).
Key/Light Switch
Low Oil Pressure
Indicator Light
Ref Kes 2
Fig. 2 Key / Light Switch
If the vehicle is equipped with lights, the key switch has
a position to operate them, indicated by the light icon.
If the vehicle is equipped with factory installed custom accesso-
ries, some accessories remain operational with the key switch
in the 'OFF' position.
DIRECTION SELECTOR
To reduce the possibility of component damage, the
vehicle must be completely stopped before moving the
direction selector.
Page 2
Fuel
Gauge
Owner's Manual and Service Guide
Located on the seat support panel, this lever permits the
selection of either 'F' (forward) or 'R' (reverse) (Ref Fig. 3
on page 2). Vehicle should be left in 'F' when unattended.
Reverse
Ref Dsl 2
Fig. 3 Direction Selector
CHOKE
The choke is used to aid cold starting (Ref. Fig. 4 on
page 2). See COLD STARTING section for operating
instructions.
LOW OIL PRESSURE INDICATOR LIGHT
A low oil pressure indicator light is located on the dash
panel (Ref Fig. 2 on page 2). The light illuminates when
the oil pressure is low. Check oil level. If oil level is
between ADD and FULL mark on dipstick, a mechanical
problem exists within the engine and the vehicle must no
be driven. Contact a local distributor or authorized
branch.
Choke
Ref Chk 1
Fig. 4 Choke
FUEL GAUGE
The fuel gauge (if equipped) will either be located on the
dash panel (electric) (Ref Fig. 2 on page 2) or directly on
the fuel tank (mechanical).
Forward
