CZ-RWSD2
Wireless Remote Remote Control
Controller
(1)
 Before installing the receiver, see the
sections on "Wiring for the Receiver" and
"Setting Address Switches". Then check
the setting of the [S003] DIP switch on the
receiver's PCB.
* Remove the cover from the receiver when
performing the PCB settings.
8
3-1. Part Names
(3) Indication lamp
Indicates operation status.
3-2. Supplied accessories
Supplied accessories
LR03 Size
Holder Battery
(1) (2)
3-3. Settings
(2) Emergency operation button
Starts/Stops emergency operation.
Operating Quick
Instructions Reference
(1) (1)
Set its address
(1) to (3)
(1) Light receiving section
Receives signals.
Wood Screw
M4 × 16
(2)
All set at OFF
when shipped
from the factory.
↑ON
Main/Sub selector
switch for remote
controllers (4)
OFF: Main ON: Sub
Clamper
(1)
