ASSEMBLY INSTRUCTIONS
STEP 1: Attaching the Wheels
1.
When assembling the wheels make sure the air valves are facing outward.
2.
Slide the wheel bushing (#19) onto the left side of the axle.
3.
Push one wheel (#15) onto the axle. Align the hole in the axle and wheel and insert
the M6x60 bolt (#24) and secure with a M6 lock nut (#9).
4.
Slide the other wheel bushing (#19) onto the right side of the axle.
5.
Push the wheel (#15) onto the axle. Slip the Ø16 flat washer (#17) and insert the
Ø5x35 cotter pin (#16) into the hole and fasten it by bending.
UK
5
